Item #:
12575
Available Refurbished
Specifications
Dimensions: 4.5" W x 3.0" H x 7.5" L
Weight: 2.5 pounds
Accuracy: +/- 3% excluding syringe variations
Infusion Modes:
Body Weight Mode:
- µg/kg/min µg/kg/min - MG/kg/min MG/kg/HR
Mass Modes:
- µg/min µg/HR - MG/min MG/HR - mU/min mU/HR - U/min U/HR
Continuous Mode:
- ml/min ml/HR
Volume Over Time Mode:
- Volume/time
Flow Rate: 0.01 to 378.0 ml/HR dependent on syringe size selected
Bolus Delivery: In Body Weight, Mass and Continuous Modes
Power: AC Adapter - DC internal rechargeable batteries
Recharge Time: No longer than 16 hours with the pump turned off
Battery Capacity: at 25ºC, a 16 hour charge will operate the pump for approximately 10 hours at 5.0 ml/hr with a 60 ml syringe.
- Alarms/Alerts:
- - Near Empty (5 to 60 minutes)
- - Empty
- - Dose Volume Delivered
- - Bolus Complete
- - Bolus Delivery
- - Occlusion
- - System Malfunction
- - Low Battery
- - Depleted Battery
- - Syringe Pops Out
- - Invalid Size
- - Invalid Number
- - Check Clutch
- - Alarm Temporary Delay: 2 or 60 minutes
- - Alarm Audio Volume: Soft or Loud
- - Load Syringe Plunger
- Status Alerts Visual, Non Audible:
- - Stop/Program
- - Deliver
- - Battery In Use
- - Battery Charging
- - Battery Depleted
- - Priming
- - Standby Mode
- - Back Light
- Total Delivery:
- - From 0.0000 to 9999.9999 MG
- - From 0.00 to 9999.99 ml
- - From 0.0000 to 9999.9999 U
- Syringe Options/Sizes:
- Becton-Dickinson (B-D®): 1,3,5,10,20,30,60 ml
- Monoject® (Mono): 1,3,6,12,20,35,60 ml
- Terumo® (Teru): 1,3,5,10,20,30,60 ml
- Becton-Dickinson Glass (BG-G) 1,3,5,10 ml
- Abboject®: 50 ml
